ACS

KHN20521-1E

KHN20521-1E

€1.450,40 EUR
€1.450,40 EUR
In offerta Esaurito

-1E

The Xtreme 200mm Race Clutch was developed with a focus on those interested in a cost-effective alternative compared to other race style clutch kits on the market but without having to compromise on quality. The 200mm Race Clutch Kit’s consist of a Billet Flywheel, Solid-centered Ceramic Clutch Plates, Cover assembly, Thrust Bearing & Carrier / or the Internal Concentric Slave Cylinder (CSC).
Clamping Force 1000kg
Torque Rating 900Nm
Bearing Contact Diameter 44-52mm
Bearing Load (@ 48mm) 218kg
Release Travel Required 6mm
Assembly Mass (without flywheel) 5.15kg
Disc Set Static Mass 0.9kg
Friction Thickness New 7mm (0.275")
Friction Thickness Worn 5.7mm (0.235")

Product Features:

  • Rigid driven disc
  • Push type billet alloy cover
  • 4140 Chromoly pressure plate
  • Hardened steel wear posts
  • Low inertia
  • Serviceable components
  • SFI certified design
Clutch Disc Diameter (mm) 200
Clutch Disc Spline Count 20
Clutch Disc Spline Diameter (mm) 22
Torque (Nm) 600
Flywheel Step +2.2mm
Design Single Plate
Stage Track Use Only
Tech Bulletins
Clamp Load
Recommended for Motorsport
Ring Gear Tooth count
Additional infotmation
Compatibility
Rover 400 XW | 416 1994.05-1998.11 D 16 A8 1590 Petrol 90 kW 122 BHP (1994.05 - 1998.11) 600 Motorsport Single Mass Flywheel
Rover 400 XW | 416 1994.05-1998.11 D 16 Z2 1590 Petrol 82 kW 112 BHP (1994.05 - 1998.11) 600 Motorsport Single Mass Flywheel
Rover 400 XW | 416 GTI/GTE 1990.04-1995.04 D 16 A9 1590 Petrol 96 kW 131 BHP (1990.04 - 1995.04) 600 Motorsport Single Mass Flywheel
Rover 400 XW | 416 GSI/GSE 1990.04-1995.04 D 16 A7 1590 Petrol 85 kW 116 BHP (1990.04 - 1995.04) 600 Motorsport Single Mass Flywheel
Rover 200 XW | 216 GTi 1990.09-1995.10 D 16 A9 1590 Petrol 96 kW 130 BHP (1990.09 - 1995.10) 600 Motorsport Single Mass Flywheel
Rover 200 XW | 216 GSi 1989.10-1995.10 D 16 A7 1590 Petrol 85 kW 116 BHP (1989.10 - 1995.10) 600 Motorsport Single Mass Flywheel
Rover 200 XW | 216 1990.04-1996.02 D 16 Z2 1590 Petrol 82 kW 111 BHP (1990.04 - 1996.02) 600 Motorsport Single Mass Flywheel
Honda Logo 1.3 (GA3) 1999.03-2002.03 D13B7 1343 Petrol 48 kW 65 BHP (1999.03 - 2002.03) 600 Motorsport Single Mass Flywheel
Honda CRX Gen. II | 1.6 i 16V (ED9) 1987.10-1989.12 D16A8, D16A9 1590 Petrol 96 kW 131 BHP (1987.10 - 1989.12) 600 Motorsport Single Mass Flywheel
Honda CRX Gen. II | 1.6 i 16V (ED9) 1987.10-1992.02 D16Z5 1590 Petrol 91 kW 124 BHP (1987.10 - 1992.02) 600 Motorsport Single Mass Flywheel
Honda CRX Gen. II | 1.4 GL 1990.01-1991.12 D14A1 1396 Petrol 66 kW 90 BHP (1990.01 - 1991.12) 600 Motorsport Single Mass Flywheel
Honda CRX Gen. I | 1.6 i 16V (AS) 1986.03-1987.10 ZC1 1590 Petrol 92 kW 125 BHP (1986.03 - 1987.10) 600 Motorsport Single Mass Flywheel
Honda Concerto 1.6 16V 1989.08-1995.03 D16A8, D16Z1, D16Z4 1590 Petrol 90 kW 122 BHP (1989.08 - 1995.03) 600 Motorsport Single Mass Flywheel
Honda Concerto 1.6 16V 1989.08-1995.03 D16Z2 1590 Petrol 82 kW 112 BHP (1989.08 - 1995.03) 600 Motorsport Single Mass Flywheel
Honda Concerto 1.6 16V 1989.08-1995.03 D16Z2 1590 Petrol 78 kW 106 BHP (1989.08 - 1995.03) 600 Motorsport Single Mass Flywheel
Honda Concerto 1.6 16V 1989.10-1992.10 D16A9 1590 Petrol 96 kW 131 BHP (1989.10 - 1992.10) 600 Motorsport Single Mass Flywheel
Honda Concerto 1.5 16V 1989.08-1995.03 D15B2 1493 Petrol 66 kW 90 BHP (1989.08 - 1995.03) 600 Motorsport Single Mass Flywheel
Honda Concerto 1.4 16V 1989.08-1991.10 D14A1, D14A8 1396 Petrol 66 kW 90 BHP (1989.08 - 1991.10) 600 Motorsport Single Mass Flywheel
Honda Concerto 1.4 16V 1989.10-1992.10 D14A1 1396 Petrol 61 kW 83 BHP (1989.10 - 1992.10) 600 Motorsport Single Mass Flywheel
Honda Civic Gen. IV | 1.6 i 16V 4x4 (EE5) 1989.10-1991.09 D16A6 1590 Petrol 80 kW 109 BHP (1989.10 - 1991.09) 600 Motorsport Single Mass Flywheel
Honda Civic Gen. IV | 1.6 i 16V (ED4) 1987.09-1991.09 D16A7 1590 Petrol 96 kW 130 BHP (1987.09 - 1991.09) 600 Motorsport Single Mass Flywheel
Honda Civic Gen. IV | 1.6 1988.01-1989.12 D16Z5 1590 Petrol 91 kW 124 BHP (1988.01 - 1989.12) 600 Motorsport Single Mass Flywheel
Honda Civic Gen. IV | 1.4 L (ED2) 1987.10-1989.12 D14A1 1396 Petrol 66 kW 90 BHP (1987.10 - 1989.12) 600 Motorsport Single Mass Flywheel
Honda Civic Gen. IV | 1.3 (ED1) 1987.10-1989.12 D13B1 1343 Petrol 55 kW 75 BHP (1987.10 - 1989.12) 600 Motorsport Single Mass Flywheel
Honda Civic Gen. IV | 1.2 1988.01-1991.12 D12B1 1187 Petrol 41 kW 56 BHP (1988.01 - 1991.12) 600 Motorsport Single Mass Flywheel
Honda Civic Gen. IV | 1.6 i 16V (ED7) 1987.10-1991.09 D16Z2 1590 Petrol 81 kW 110 BHP (1987.10 - 1991.09) 600 Motorsport Single Mass Flywheel
Honda Civic Gen. IV | 1.5 i 16V (ED6) 1988.10-1991.09 D15B2 1493 Petrol 66 kW 90 BHP (1988.10 - 1991.09) 600 Motorsport Single Mass Flywheel
Honda Civic Gen. IV | 1.5 1988.01-1989.12 D15B1 1493 Petrol 60 kW 82 BHP (1988.01 - 1989.12) 600 Motorsport Single Mass Flywheel
Honda Civic Gen. IV | 1.4 L (EC9) 1987.10-1989.12 D14A1 1396 Petrol 66 kW 90 BHP (1987.10 - 1989.12) 600 Motorsport Single Mass Flywheel
Honda Civic Gen. IV | 1.3 16V Cat (EC8) 1989.09-1991.09 D13B2 1343 Petrol 55 kW 75 BHP (1989.09 - 1991.09) 600 Motorsport Single Mass Flywheel
Honda Civic Gen. IV | 1.3 (EC8) 1987.10-1989.12 D13B1 1343 Petrol 55 kW 75 BHP (1987.10 - 1989.12) 600 Motorsport Single Mass Flywheel
