KGM23017-1A

Recommended for: Street use in vehicles with minor engine modifications.

Sprung organic clutch kits offer exceptional driveability for vehicles used daily but also have performance modifications. The sprung organic disc offers improved dampening which reduces the shock loading on the transmission.

• Torque capacity 270Nm

• Clamp load Increased over standard
• Organic Friction Discs
• Heavy Duty Pressure Plate
• Kit contains everything you need for a successful installation + accessories

At Xtreme Clutch, we strive to offer a variety of clutch options for each vehicle to ensure a clutch solution is available for every vehicle application. Whether you are modifying a road vehicle or building a race car from scratch, we have the clutch solution for you. Our upgrades are divided into different stages depending on the friction disc material and the number of friction discs.

Xtreme Performance upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.

Clutch Disc Diameter (mm)	228
Clutch Disc Spline Count	14
Clutch Disc Spline Diameter (mm)	25
Torque (Nm)	270
Flywheel Step	-19.2mm
Design	Single Plate
Stage	Stage 1
Tech Bulletins
Clamp Load
Recommended for	Street Performance & Towing - Stage 1
Ring Gear Tooth count
Additional infotmation

Compatibility
Vauxhall	Zafira	2.0 GSI Turbo (T98)	2001.09-2005.06	Z 20 LET 1998 Petrol 141 kW 192 BHP (2001.09 - 2005.06)
Opel	Zafira	2.0 OPC (F75)	2001.09-2005.06	Z 20 LET 1998 Petrol 141 kW 192 BHP (2001.09 - 2005.06)
Opel	Zafira	2.0 OPC (F75)	2002.11-2005.06	Z 20 LET 1998 Petrol 147 kW 200 BHP (2002.11 - 2005.06)
Opel	Speedster	2.0 Turbo (R97)	2002.08-2006.08	Z 20 LET 1998 Petrol 147 kW 200 BHP (2002.08 - 2006.08)
Opel	Astra	G | 2.0 16V Turbo	2000.09-2001.08	Z 20 LET 1998 Petrol 140 kW 190 BHP (2000.09 - 2001.08)
Vauxhall	Astra	G | 2.0 16V Turbo	2000.09-2005.08	Z 20 LET 1998 Petrol 140 kW 190 BHP (2000.09 - 2005.08)
Opel	Astra	G | 2.0 16V Turbo	2001.08-2005.05	Z 20 LET 1998 Petrol 141 kW 192 BHP (2001.08 - 2005.05)
Opel	Astra	G | 2.0 16V Turbo	2002.11-2005.10	Z 20 LET 1998 Petrol 147 kW 200 BHP (2002.11 - 2005.10)
Opel	Astra	G | 2.0 OPC	2002.11-2004.07	Z 20 LET 1998 Petrol 147 kW 200 BHP (2002.11 - 2004.07)
Vauxhall	Astra	G | 2.0 SRI Turbo (F08)	2001.11-2005.05	Z 20 LET 1998 Petrol 141 kW 192 BHP (2001.11 - 2005.05)
Vauxhall	Astra	G | 2.0 Turbo	2002.03-2005.10	Z 20 LET 1998 Petrol 141 kW 192 BHP (2002.03 - 2005.10)
Holden	Astra	TS | 2.0i Turbo	2003.05-2004.07	Z 20 LET 1998 Petrol 147 kW 200 BHP (2003.05 - 2004.07)
Holden	Astra	TS | 2.0i Turbo	2002.06-2004.07	Z 20 LET, Z 20 LER 1998 Petrol 147 kW 200 BHP (2002.06 - 2004.07)
