KFD28015-1B

Recommended for: Motorsport Applications

These kits are available with sprung ceramic friction discs and are designed for motorsport applications where higher heat and torque capacity is required. These can also be used in some road applications.

• Torque capacity 900Nm
• Clamp load 1300kg 20% Increased over standard
• Sprung Ceramic Friction Disc
• Heavy Duty Pressure Plate
• Kit contains everything you need for a successful installation + accessories

The sprung ceramic range of kits have been developed for motorsport applications where a higher heat and torque capacity is required. These discs utilise a sprung hub that helps to reduce shock loading and are commonly used in track cars that retain the factory transmission.

At Xtreme Clutch, we strive to offer a variety of clutch options for each vehicle to ensure a clutch solution is available for every vehicle application. Whether you are modifying a road vehicle or building a race car from scratch, we have the clutch solution for you. Our upgrades are divided into different stages depending on the friction disc material and the number of friction discs.

Xtreme Performance upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.

Clutch Disc Diameter (mm)	280
Clutch Disc Spline Count	10
Clutch Disc Spline Diameter (mm)	27
Torque (Nm)	890
Flywheel Step	0
Design	Single Plate
Stage	Stage 2
Tech Bulletins
Clamp Load	1300Kg (20% inc.)
Recommended for	Track - Stage 2
Ring Gear Tooth count
Additional infotmation

Compatibility
Ford	Mustang	4.6	1998.09-2004.12	999SMPI 4601 Petrol 192 kW 261 BHP (1998.09 - 2004.12)
Ford	Mustang	4.6 V8	1999.06-2000.10	999SMPI 4601 Petrol 192 kW 261 BHP (1999.06 - 2000.10)
Ford	Mustang	4.6 V8	1995.11-1999.05	99WSFI 4601 Petrol 160 kW 218 BHP (1995.11 - 1999.05)
Ford	Mustang	4.6 V8	1995.11-1999.05	99WSFI 4601 Petrol 165 kW 224 BHP (1995.11 - 1999.05)
Ford	Mustang	4.6 V8	1995.11-1999.05	V99V 4601 Petrol 225 kW 306 BHP (1995.11 - 1999.05)
Ford	Mustang	4.6 V8	1999.06-2003.09	V99V 4601 Petrol 236 kW 321 BHP (1999.06 - 2003.09)
