DBA53951.1XS

5000 series - T3 Slotted - Rotor Only

Diameter [mm]	400
Thickness [mm]	34
Disc Vent	Kangaroo Paw
Stage	Stage 5
Tech Bulletins	Bedding in Brakes
Tech Bulletins	How to clean a Disc Rotor before fitting
Tech Bulletins	Motorsport - Important Info
Annulus [mm] (Maximum useable pad width)	68.5
Pitch Circle Diameter (P.C.D.)	240
Diameter & Number of Bolt Holes [mm]	9mm (x12)
Air Gap [mm]	12
Offset [mm]	n/a
Flange Inside Diameter [mm]	216
Flange Thickness [mm]	7
Hole Type	Round
Center Hole [mm]	216

Compatibility
DODGE	Challenger SRT Redeye	6.2 Supercharged (2020-)	2020-	Brake Caliper: Brembo	Front	Brake Pads: DB2375	Disc Diameter [mm]: 400
DODGE	Charger SRT Redeye	6.2 Supercharged (2020-)	2020-	Brake Caliper: Brembo	Front	Brake Pads: DB2375	Disc Diameter [mm]: 400
