7055R

Pedders Coil Spring

Pedders Coil Springs are Pedder's premium range of Coil Springs for multiple applications. Built to ISO 9001 standards with tolerance of only +/-2mm at loaded height. Pedders Coil Springs are simply unrivaled in terms of handling, vehicle appearance and performance. Coil Spring design and manufacturing is a craft which requires strict adherence to a demanding series of procedures, all of which are critical to the performance of the final product.

The spring rate, or stiffness, must be matched to the weight of the vehicle resting on it and the weight of the other suspension components and the wheel. Spring rate also controls roll stiffness, or body roll. By reducing the amount of body roll, we reduce the amount of wheel camber change. Large camber change can drastically reduce the tyre’s contact with the road surface, severely limiting the handling potential during cornering.

The handling of most vehicles is substantially improved by increasing the original spring rate to an optimum rate which maximises tyre adhesion and reduces body roll for better handling. Increasing the spring rate beyond the optimum rate detracts from the handling potential as the tyres begin to skip over bumps, reducing grip and safety.

Features & Benefits

• Hot Coiling
• Oil Quenching
• Furnace Tempering
• Shot Peening
• Scragging
• Loaded Height and Rate Testing
• Powder Coating and Packaging

Spring rate [kgf/mm]	2,33
Load at Nominal Ride Height [kgs]	262
Height at Nominal Ride Height [mm]	194
Spring Rate [lbf/in]	129.8
Free Height [mm]	315

Compatibility
Hyundai	Excel	HA, X1, With Repairable Struts	HA, X1, With Repairable Struts | 1986-1990	SPRINGS AND SHOCKS	Front Spring Standard	Pedders Heavy Duty Coil Spring
Hyundai	Excel	HU, X2, With Sealed Struts	HU, X2, With Sealed Struts | 1989-1994	SPRINGS AND SHOCKS	Front Spring Standard	Pedders Heavy Duty Coil Spring
Hyundai	Excel	3 Door Van	3 Door Van | 1991-1994	SPRINGS AND SHOCKS	Front Spring Standard	Pedders Heavy Duty Coil Spring
Mazda	323, Incl Protege & Astina	BF5R, BFMR,BF8 4wd	BF5R, BFMR,BF8 4wd | 1985-1989	SPRINGS AND SHOCKS	Rear Spring Standard	Pedders Heavy Duty Coil Spring
Mazda	323, Incl Protege & Astina	BG8	BG8 | 1989-1994	SPRINGS AND SHOCKS	Rear Spring Standard	Pedders Heavy Duty Coil Spring
Mitsubishi	Colt	RA	RA | 1980-1982	SPRINGS AND SHOCKS	Front Spring Standard	Pedders Heavy Duty Coil Spring
Mitsubishi	Colt	RB, RC, RD & RE	RB, RC, RD & RE | 1982-1990	SPRINGS AND SHOCKS	Front Spring Standard	Pedders Heavy Duty Coil Spring
Nissan	Bluebird	910 Series 1, Sedan	910 Series 1, Sedan | 1981-1983	SPRINGS AND SHOCKS	Front Spring Standard	Pedders Heavy Duty Coil Spring
Nissan	Bluebird	910 Series 1, Wagon	910 Series 1, Wagon | 1981-1983	SPRINGS AND SHOCKS	Front Spring Standard	Pedders Heavy Duty Coil Spring
Nissan	Bluebird	910 Series 2 & 3, Sedan	910 Series 2 & 3, Sedan | 1983-1986	SPRINGS AND SHOCKS	Front Spring Standard	Pedders Heavy Duty Coil Spring
Nissan	Bluebird	910 Series 2 & 3, Wagon	910 Series 2 & 3, Wagon | 1983-1986	SPRINGS AND SHOCKS	Front Spring Standard	Pedders Heavy Duty Coil Spring
Nissan	Pulsar	N15 Including SSS	N15 Including SSS | 1995-2000	SPRINGS AND SHOCKS	Front Spring Standard	Pedders Heavy Duty Coil Spring
