KNI18001-1C

Recommended for: Motorsport Applications

These kits are available with cushioned ceramic friction discs and are designed for motorsport applications where higher heat and torque capacity is required. These can also be used in some road applications.

• Torque capacity 270Nm
• Clamp load Increased over standard
• Cushioned Ceramic Friction Disc
• Heavy Duty Pressure Plate
• Kit contains everything you need for a successful installation + accessories

The Xtreme Clutch cushioned ceramic range of upgrades offers exceptional heat capacity and torque capacity whilst providing cushioning between the friction surfaces of the disc, ensuring excellent driveability. The discs still retain the sprung hub that helps to reduce shock loading. These kits are commonly used in vehicles that are used on the road occasionally but mainly focused on track applications.

At Xtreme Clutch, we strive to offer a variety of clutch options for each vehicle to ensure a clutch solution is available for every vehicle application. Whether you are modifying a road vehicle or building a race car from scratch, we have the clutch solution for you. Our upgrades are divided into different stages depending on the friction disc material and the number of friction discs.Xtreme Performance upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.

Clutch Disc Diameter (mm)	180
Clutch Disc Spline Count	18
Clutch Disc Spline Diameter (mm)	20.5
Torque (Nm)	270
Flywheel Step
Design	Single Plate
Stage	Stage 2
Tech Bulletins
Clamp Load
Recommended for	Track - Stage 2
Ring Gear Tooth count
Additional infotmation

Compatibility
Nissan	Sunny	B11 | 1.3	1982.08-1990.08	E13 1269 Petrol 44 kW 60 BHP (1982.08 - 1990.08)	270	Track Use	Not included
Nissan	Sunny	B11 | 1.5	1982.03-1986.10	E15S 1488 Petrol 55 kW 75 BHP (1982.03 - 1986.10)	270	Track Use	Not included
Nissan	Sunny	B11 | 1.5	1982.03-1986.05	E15 1488 Petrol 51 kW 69 BHP (1982.03 - 1986.05)	270	Track Use	Not included
Nissan	Sunny	B11 |1.7 D	1982.03-1986.10	CD17 1681 Diesel 40 kW 54 BHP (1982.03 - 1986.10)	270	Track Use	Not included
Nissan	Sunny	B12/N13 | 1.0	1986.07-1990.09	E10S 988 Petrol 37 kW 50 BHP (1986.07 - 1990.09)	270	Track Use	Not included
Nissan	Sunny	B12/N13 | 1.3	1986.07-1991.10	E13S 1269 Petrol 44 kW 60 BHP (1986.07 - 1991.10)	270	Track Use	Not included
Nissan	Sunny	B12/N13 | 1.3	1986.06-1988.10	E13S 1269 Petrol 44 kW 60 BHP (1986.06 - 1988.10)	270	Track Use	Not included
Nissan	Sunny	B12/N13 | 1.4	1988.10-1990.09	GA14DS 1392 Petrol 60 kW 82 BHP (1988.10 - 1990.09)	270	Track Use	Not included
Nissan	Sunny	B12/N13 | 1.4	1988.10-1991.08	GA14S 1392 Petrol 55 kW 75 BHP (1988.10 - 1991.08)	270	Track Use	Not included
Nissan	Sunny	B13/N14 | 1.4	1990.10-1995.06	GA14DS 1392 Petrol 60 kW 82 BHP (1990.10 - 1995.06)	270	Track Use	Not included
Nissan	Sunny	B13/N14 | 1.4	1990.10-1995.05	GA14DE, GA14DS 1392 Petrol 55 kW 75 BHP (1990.10 - 1995.05)	270	Track Use	Not included
Nissan	Sunny	B13/N14 | 1.4 16V	1990.10-1995.06	GA14DE 1392 Petrol 64 kW 87 BHP (1990.10 - 1995.06)	270	Track Use	Not included
Nissan	Micra	K11 | 1.0 16V	2000.07-2003.02	CG10DE 998 Petrol 44 kW 60 BHP (2000.07 - 2003.02)	270	Track Use	Not included
Nissan	Micra	K11 | 1.4 16V	2000.09-2003.02	CGA3DE 1348 Petrol 60 kW 82 BHP (2000.09 - 2003.02)	270	Track Use	Not included
Nissan	Prairie	M10 | 1.5 S	1984.01-1987.12	E15S 1488 Petrol 55 kW 75 BHP (1984.01 - 1987.12)	270	Track Use	Not included
Nissan	Cherry	N10 | 1.3	1981.09-1983.12	E13 1269 Petrol 44 kW 60 BHP (1981.09 - 1983.12)	270	Track Use	Not included
Nissan	Cherry	N10 | 1.5	1981.08-1982.12	E15 1488 Petrol 51 kW 69 BHP (1981.08 - 1982.12)	270	Track Use	Not included
Nissan	Cherry	N12 | 1.3	1982.05-1986.10	E13 1269 Petrol 44 kW 60 BHP (1982.05 - 1986.10)	270	Track Use	Not included
Nissan	Cherry	N12 | 1.5	1983.11-1986.10	E15S 1488 Petrol 55 kW 75 BHP (1983.11 - 1986.10)	270	Track Use	Not included
Nissan	Cherry	N12 | 1.6	1984.05-1986.07	E16 1597 Petrol 51 kW 69 BHP (1984.05 - 1986.07)	270	Track Use	Not included
Nissan	Cherry	N12 | 1.7 D	1982.10-1986.12	CD17 1681 Diesel 40 kW 54 BHP (1982.10 - 1986.12)	270	Track Use	Not included
Nissan	Almera	N15 | 1.4	1995.09-2000.07	GA14DE 1392 Petrol 64 kW 87 BHP (1995.09 - 2000.07)	270	Track Use	Not included
Nissan	Almera	N15 | 1.4	1995.09-2000.07	GA14DE 1392 Petrol 55 kW 75 BHP (1995.09 - 2000.07)	270	Track Use	Not included
