KMI23003-1B

Recommended for: Motorsport Applications

These kits are available with sprung ceramic friction discs and are designed for motorsport applications where higher heat and torque capacity is required. These can also be used in some road applications.

• Torque capacity 490Nm
• Clamp load 750kg 30% Increased over standard
• Sprung Ceramic Friction Disc
• Heavy Duty Pressure Plate
• Kit contains everything you need for a successful installation + accessories

The sprung ceramic range of kits have been developed for motorsport applications where a higher heat and torque capacity is required. These discs utilise a sprung hub that helps to reduce shock loading and are commonly used in track cars that retain the factory transmission.

At Xtreme Clutch, we strive to offer a variety of clutch options for each vehicle to ensure a clutch solution is available for every vehicle application. Whether you are modifying a road vehicle or building a race car from scratch, we have the clutch solution for you. Our upgrades are divided into different stages depending on the friction disc material and the number of friction discs.

Xtreme Performance upgrade kits are available with everything you need for a successful installation + accessories you may want to upgrade or replace while the gearbox is out of the vehicle.

Clutch Disc Diameter (mm)	225
Clutch Disc Spline Count	20
Clutch Disc Spline Diameter (mm)	22.4
Torque (Nm)	490
Flywheel Step	-1.0mm/.040""
Design	Single Plate
Stage	Stage 2
Tech Bulletins
Clamp Load	750Kg (30% inc.)
Recommended for	Track - Stage 2
Ring Gear Tooth count
Additional infotmation

Compatibility
Mitsubishi	Magna	2.6 (TR)	1991.10-1994.02	4G54 2555 Petrol 85 kW 116 BHP (1991.10 - 1994.02)	490	Track Use	Not included
Mitsubishi	Magna	2.6 (TS)	1994.02-1996.04	4G54 2555 Petrol 85 kW 116 BHP (1994.02 - 1996.04)	490	Track Use	Not included
Mitsubishi	Magna	2.6 (TS)	1994.03-1996.04	4G54 2555 Petrol 98 kW 133 BHP (1994.03 - 1996.04)	490	Track Use	Not included
Mitsubishi	Magna	2.6 (TR)	1991.10-1994.02	4G54 2555 Petrol 96 kW 131 BHP (1991.10 - 1994.02)	490	Track Use	Not included
Mitsubishi	Magna	2.6 (TR)	1991.04-1994.02	4G54 2555 Petrol 98 kW 133 BHP (1991.04 - 1994.02)	490	Track Use	Not included
Mitsubishi	Magna	2.6 (TS)	1994.02-1996.04	4G54 2555 Petrol 98 kW 133 BHP (1994.02 - 1996.04)	490	Track Use	Not included
Mitsubishi	Magna	2.6 (TR)	1991.05-1994.02	G54B 2554 Petrol 114 kW 155 BHP (1991.05 - 1994.02)	490	Track Use	Not included
