DBA
DBA42394S
DBA42394S
Regular price
€305,71 EUR
Regular price
Sale price
€305,71 EUR
Quantity
Couldn't load pickup availability
| Feature Description | Advantage | Benefit |
 "T3 Slot 48 precision CNC machined slots"
|
Tri-Symmetrical curve slots dampens the vibration harmonics or noise | A quieter, responsive and smoother brake pedal feel |
| Increased number of out-gassing exit points for brake pad friction gasses to escape through | Increases the consistency and effectiveness of every brake stop | |
| Universal slot design | Eliminates the need for left and right discs | |
 "KANGAROO_PAW") Kangaroo Paw – 144 diamond and tear drop pillar ventilation system
|
Increased surface area resulting in greater heat dissipation | Minimises brake fade and increases braking effectiveness |
| Increased surface area resulting in greater heat dissipation | Prolongs service life for both pads and rotors. Reduces mechanical damage and associated costs | |
 XG150 High Carbon Alloyed Iron
|
An increase in thermal capacity property allows the rotor to handle constant extremes of heat over extended periods of time | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermal Stability Profiling
|
Special formulation designed to respond to DBA’s TSP process | Minimises warping and cracking and prolongs the service life of the rotor |
 Thermographic Temperature Monitoring
|
Heat paint markings change colour at specific temperature thresholds | Offers the driver a clear indication of peak braking temperatures |
| When temperature thresholds are exceeded paint markings will permanently change colours | Allows the driver to monitor rotor fatigue and decide on rotor replacement and to assist resellers with warranty claims | |
 Paint protection on non-friction areas
|
Reduces corrosion | Stops any unsightly rust formation |
| Enhances appearance | Adds value to the product |
| Diameter [mm] | 318 |
| Disc Vent | Kangaroo Paw |
| Number of Holes | 5 |
| Inner Diameter [mm] | 98 |
| Minimum Thickness [mm] | 26 |
| Thickness [mm] | 28 |
| Height [mm] | 67 |
| Pitch Circle [mm] | 130 |
| Stage | Stage 4 |
| Tech Bulletins | Bedding in Brakes |
| Tech Bulletins | How to clean a Disc Rotor before fitting |
| Tech Bulletins | Motorsport - Important Info |
| ECE R90 number | E11*90R02/06*60514*00 |
| Compatibility | ||||||
|---|---|---|---|---|---|---|
| PORSCHE | 911 (996) | 3.4 Carrera (1997-2002) | 1997-2002 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | 911 (996) | 3.4 Carrera 4 (1997-2002) | 1997-2002 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | 911 (996) | 3.4 Carrera 4 Cast Iron Disc Only (2002-2005) | 2002-2005 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | 911 (996) | 3.4 Carrera Cast Iron Disc Only (2002-2005) | 2002-2005 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | 911 (996) | 3.6 Carrera 4 Cast Iron Disc Only (2001-2005) | 2001-2005 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | 911 (996) | 3.6 Carrera Cast Iron Disc Only (2001-2005) | 2001-2005 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | 911 (996) | 3.6 Carrera Targa 320BHP Cast Iron Disc Only (2002-2005) | 2002-2005 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | 911 (997) | 3.6 Carrera 4 Cast Iron Disc Only (2005-2007) | 2005-2007 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | 911 (997) | 3.6 Carrera 4 Targa 325BHP Cast Iron Disc Only (2006-2009) | 2006-2009 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | 911 (997) | 3.6 Carrera Cast Iron Disc Only - Sport Package (2005-2008) | 2005-2008 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | 911 (997) | 3.6 Carrera Cast Iron Disc Only (2004-2008) | 2004-2008 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | Boxster (986) | 3.2 S Cast Iron Disc Only (2000-2004) | 2000-2004 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | Boxster (987) | 2.9 Cast Iron Disc Only (2009-2012) | 2009-2012 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | Boxster (987) | 3.2 S Cast Iron Disc Only (2004-2006) | 2004-2006 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | Boxster (987) | 3.4 S 295BHP Cast Iron Disc Only (2006-2008) | 2006-2008 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | Boxster (987) | 3.4 S 310BHP Cast Iron Disc Only (2008-2012) | 2008-2012 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | Boxster Spyder | 3.4 324BHP Cast Iron Disc Only (2010-2015) | 2010-2015 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | Cayman (987) | 2.9 Cast Iron Disc Only (2009-2012) | 2009-2012 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | Cayman (987) | 3.4 R 330BHP Cast Iron Disc Only (2010-2012) | 2010-2012 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | Cayman (987) | 3.4 S Cast Iron Disc Only (2005-2006) | 2005-2006 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | Cayman (987) | 3.4 S Cast Iron Disc Only (2006-2009) | 2006-2009 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | Cayman (987) | 3.4 S Cast Iron Disc Only (2009-2012) | 2009-2012 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
| PORSCHE | Cayman (987) | 3.4 S Sport Cast Iron Disc Only (2008-2012) | 2008-2012 | Brake Caliper: Brembo | Front | Disc Diameter [mm]: 318 |
